NUP Series Cylindrical Roller Bearings

The NUP series cylindrical roller bearings are heavy-duty, separable bearings capable of bidirectional positioning. Their structural features include an inner ring with dual flanges and a removable locating ring (flat retaining ring), while the outer ring also features dual flanges. These bearings can withstand significant radial loads and reliably handle bidirectional axial loads, effectively limiting axial movement of the shaft in both directions to achieve precise axial positioning. This series of bearings offers high rigidity and load-carrying capacity, with outstanding radial load performance and stable operating precision. Since the inner ring, outer ring, and rolling elements can be completely separated, installation, disassembly, and maintenance are highly convenient. They are suitable for transmission components with strict axial positioning requirements, high loads, and relatively complex operating conditions, and are widely used in machine tool spindles, reducers, gearboxes, motors, pumps, compressors, and various medium-to-heavy-duty mechanical equipment. They are particularly well-suited for applications requiring simultaneous resistance to radial forces and bidirectional axial forces, as well as smooth operation and reliable positioning. Thanks to their reliable structure, ease of installation and removal, and balanced load-carrying capacity, they have become a commonly used locating cylindrical roller bearing in industrial transmission systems.


NUP Series Cylindrical Roller Bearings

Product Parameters

Inquiry Model Basic Dimensions (mm) Rated Load (kN) Limiting Speed (r/min) Weight
≈kg
model d D B C Dynamic C0 Static Ref. Lim.
✉️ NUP203M 17 40 12 17200 14300 19000 22000 0.07
✉️ NUP2203M 17 40 16 23800 21600 19000 22000 0.093
✉️ NUP303M 17 47 14 24600 20400 15000 20000 0.12
✉️ NUP203W 17 40 12 17200 14300 19000 22000 0.07
✉️ NUP2203W 17 40 16 23800 21600 19000 22000 0.093
✉️ NUP303W 17 47 14 24600 20400 15000 20000 0.12
✉️ NUP203ET 17 40 12 17200 14300 19000 22000 0.07
✉️ NUP2203ET 17 40 16 23800 21600 19000 22000 0.093
✉️ NUP303ET 17 47 14 24600 20400 15000 20000 0.12
✉️ NUP204EM 20 47 14 25700 22600 13000 16000 0.107
✉️ NUP2204M 20 47 18 20700 18400 11000 19000 0.144
✉️ NUP304EM 20 52 15 31500 26900 12000 13000 0.145
✉️ NUP2304EM 20 52 21 30500 27200 11000 14000 0.217
✉️ NUP204W 20 47 14 25700 22600 13000 16000 0.107
✉️ NUP2204W 20 47 18 20700 18400 11000 19000 0.144
✉️ NUP304W 20 52 15 31500 26900 12000 13000 0.145
✉️ NUP2304W 20 52 21 30500 27200 11000 14000 0.217
✉️ NUP204ET 20 47 14 25700 22600 13000 16000 0.107
✉️ NUP2204ET 20 47 18 20700 18400 11000 19000 0.144
✉️ NUP304ET 20 52 15 31500 26900 12000 13000 0.145
