NF Series Cylindrical Roller Bearings

NF-type cylindrical roller bearings feature a double flange on the inner ring and a single flange on the outer ring. They can withstand radial loads and unidirectional axial loads, and are capable of restricting axial displacement of the shaft in one direction.

With a separable design that facilitates installation and removal, these bearings offer excellent rigidity and load-carrying capacity. They are suitable for transmission equipment such as gearboxes, machine tools, and electric motors that require unidirectional axial positioning and operate at high speeds.

Product Parameters

Inquiry	Model	Basic Dimensions (mm)			Rated Load (kN)		Limiting Speed (r/min)		Weight ≈kg
Inquiry	model	d	D	B	C Dynamic	C0 Static	Ref.	Lim.	Weight ≈kg
✉️	NF203M	17	40	12	17.2	14.3	19000	22000	0.066
✉️	NF203W	17	40	12	17.2	14.3	19000	22000	0.066
✉️	NF203ET	17	40	12	17.2	14.3	19000	22000	0.066
✉️	NF204M	20	47	14	15.4	12.7	12000	18000	0.107
✉️	NF304M	20	52	15	21.4	17.3	10000	14000	0.148
✉️	NF2204EM	20	47	18	38.5	31	14000	19200	0.144
✉️	NF2304EM	20	52	21	49.5	39	12000	16800	0.212
✉️	NF204W	20	47	14	15.4	12.7	12000	18000	0.107
✉️	NF304W	20	52	15	21.4	17.3	10000	14000	0.148
✉️	NF2204W	20	47	18	38.5	31	14000	19200	0.144
✉️	NF2304W	20	52	21	49.5	39	12000	16800	0.212
✉️	NF204ET	20	47	14	15.4	12.7	12000	18000	0.107
✉️	NF304ET	20	52	15	21.4	17.3	10000	14000	0.148
✉️	NF2204ET	20	47	18	38.5	31	14000	19200	0.144
✉️	NF2304ET	20	52	21	49.5	39	12000	16800	0.212
✉️	NF205M	25	52	15	17.7	15.7	10000	16000	0.135
✉️	NF305M	25	62	17	29.3	25.2	8000	12000	0.233
✉️	NF405M	25	80	21	46.5	40	7100	9500	0.536
✉️	NF2205EM	25	52	18	41.5	34.5	11000	15600	0.163
✉️	NF2305EM	25	62	24	67.5	56	9700	13200	0.345
