NU Series Cylindrical Roller Bearings

NU-type cylindrical roller bearings feature a double flange on the inner ring and no flange on the outer ring. They are primarily designed to withstand purely radial loads, allowing for bidirectional axial movement between the shaft and the housing, thereby effectively compensating for thermal expansion and contraction of the shaft.

With high load-carrying capacity, high rigidity, and good speed adaptability, these bearings have a separable design that facilitates easy installation and removal. They are commonly used in transmission components requiring free expansion and contraction, such as electric motors, fans, machine tools, and gearboxes.

NU Series Cylindrical Roller Bearings

Product Parameters

Inquiry Model Basic Dimensions (mm) Rated Load (kN) Limiting Speed (r/min) Weight
≈kg
model d D B C Dynamic C0 Static Ref. Lim.
✉️ NU202M 15 35 11 12.5 10.2 22000 26000 0.048
✉️ NU202W 15 35 11 12.5 10.2 22000 26000 0.048
✉️ NU202ET 15 35 11 12.5 10.2 22000 26000 0.048
✉️ NU203M 17 40 12 17.2 14.3 19000 22000 0.07
✉️ NU2203M 17 40 16 23.8 21.6 19000 22000 0.093
✉️ NU303M 17 47 14 24.6 20.4 15000 20000 0.12
✉️ NU203W 17 40 12 17.2 14.3 19000 22000 0.07
✉️ NU2203W 17 40 16 23.8 21.6 19000 22000 0.093
✉️ NU303W 17 47 14 24.6 20.4 15000 20000 0.12
✉️ NU203ET 17 40 12 17.2 14.3 19000 22000 0.07
✉️ NU2203ET 17 40 16 23.8 21.6 19000 22000 0.093
✉️ NU303ET 17 47 14 24.6 20.4 15000 20000 0.12
✉️ NU204EM 20 47 14 25.7 22.6 13000 16000 0.107
✉️ NU2204M 20 47 18 20.7 18.4 11000 19000 0.144
✉️ NU304EM 20 52 15 31.5 26.9 12000 13000 0.145
✉️ NU2304EM 20 52 21 30.5 27.2 11000 14000 0.217
✉️ NU204W 20 47 14 25.7 22.6 13000 16000 0.107
✉️ NU2204W 20 47 18 20.7 18.4 11000 19000 0.144
✉️ NU304W 20 52 15 31.5 26.9 12000 13000 0.145
✉️ NU2304W 20 52 21 30.5 27.2 11000 14000 0.217
